Image de High Frequency Online N-C6-20K Series

High Frequency Online N-C6-20K Series

SKU: FS00018891
Reproduction is welcome and allowed for free circulation only.

Key features
��High frequency and double conversion online UPS
�� Single phase, Power Factor 0.8
�� Fully digitized microprocessor control�� Wide input voltage range�� Advanced PFC technology�� Self-testing when UPS startup�� Advanced battery management�� Automatic battery charging in UPS off mode�� Lightning and surge protection�� Short circuit and overload protection�� Smart RS232 communication with monitoring software�� Battery voltage and load capacity display�� SNMP card optional�� LCD display and EPO��ECO Function optional�� N+X parallel design optional

Technical Specifications

ITEM

MODEL

N-C6K

N-C6KS

N-C10K

N-C10KS

N-C15KS

N-C20KS

Capacity

VA / Watts

6KVA / 4.8KW

10KVA / 8KW

15KVA / 12KW

20KVA / 14KW

Input

Normal voltage

220VAC, L+N+G

Input Voltage range

120V-275V

Frequency range

50/60��10%

Input power factor

>0.99(220VAC,full R load)

Generator

Support generator input(Generator rating��2*UPS rating

Output

Voltage range

220VAC+-1%

Frequency range

48Hz/54Hz(AC mode), 50HzX(1��0.1��)(Battery mode)

Wave form

Pure Sine Wave

Transfer Time

0 ms

Distortion (Full Load) linear load

< 3%

distortion (Ful l Load) nonlinear load

< 5%

Overload capacity

105%~125% ,1min then transfer to bypass and alarm. 125%~150% 30s then transfer to bypass and alarm,1min then cut off output. >150% ,0.5s then transfer to bypass and alarm.

Load peak ratio

3:1(max)

Battery

Type

Maintenance free valve regulated lead acid (VRLA) battery

Battery voltage

192VDC

192VDC

192VDC

192VDC

192VDC

192VDC

Battery Capacity

internal 16*7AH

External

internal 16*7AH

External

External

External

Around backup time (Full load)

4Mins

up to external battery capacity

3Mins

up to external battery capacity

Around backup time (Half load)

12Mins

9mMins

up to external battery capacity

Recharge time

7 hours to 90%capacity

up to external battery capacity

7 hours to 90%capacity

up to external battery capacity

LED Display

LED

Load level / Battery level / Battery mode / Line mode / Inverter /B ypass /Over load / Fault

Audible Alarm

Battery Mode

Beeping every 4 seconds (re-settable) and every second when battery

Overload

Beeping twice every second

UPS Fault

Beeping Continuously

Bettery low/charger fault

Beeping every 1 second

Bypass mode

Beeping every 2 min

L/N inverse

Beeping every 2 min

Communications

RS-232 Interface

With monitoring software

Working Environment

Working temperature

- 20��~40��

Humidity

0-95% non-condensing

product dimension

WxDxH (mm)

248*500*616

240*500*460

248*500*616

240*500*460

248*500*616

248*500*616

Package size

WxDxH (mm)

700*385*851

595*390*578

700*385*851

595*390*578

700*385*851

700*385*851

Package weight

N.weight(Kg)

57

18

67.5

20

35

35

Gross weight(Kg)

71

23

77.5

27.5

45

45

optional functions

ECO

optional

EPO

optional

LCD display (optional)

input / output VAC & HZ, Load Rate,Battery Rate,Temp.

REMARK

C*k --- Standard Type, C*Ks(-N)---- Long Time Type
