Picture of 23.8-inch 1920*1080 resolution 144 Hz  computer lcd module

23.8-inch 1920*1080 resolution 144 Hz computer lcd module

SKU: FS9103743
Panel size 23.8 inches Panel type a-Si TFT-LCD, LCD module Resolution 1920 (RGB) × 1080 [FHD] 92PPI pixel arrangement RGB vertical stripe Display area 527.04 (W) × 296.46 (H) mm
Reproduction is welcome and allowed for free circulation only.


23.8-inch 1920*1080 resolution 144 Hz computer lcd module

Panel size 23.8 inches Panel type a-Si TFT-LCD, LCD module

Resolution 1920 (RGB) × 1080 [FHD] 92PPI pixel arrangement RGB vertical stripe

Display area 527.04 (W) × 296.46 (H) mm

Appearance size 535 (W) × 313 (H) × 15.35 (D) mm surface treatment haze (Haze 25%), Hard coating (3H)

Panel brightness 350 cd/m ² (Typ.) Contrast 1000:1 (Typ.) (TM)

Visual angle 89/89/89/89 (Typ.) (CR ≥ 10) working mode ADS, normally black display, transparent

Reaction time 5 (Typ.) (G to G) ms

Display color 16.7M, 99% sRGB light source type WLED, 30K hours, without driver

Operating frequency 144Hz, touch screen without touch

Screen weight 2.23/2.43Kgs (Typ./Max.) panel application

Signal interface LVDS (4 ch, 8-bit), 92 pins terminal

Drive screen voltage 5.0V (Typ.)

Operating environment: 0~50 ° C Storage: -20~60 ° C


Key attributes
Industry-specific attributes
Type
TFT
Display Size
23.8-inch
Other attributes
Supplier Type
Computer monitor
Place of Origin
China
Brand Name
BOE
Type
A-Si TFT-LCD
Resolution
1920*1080
Interface
LVDS
Product Name
LCD Dispaly Screen
Contrast Ratio
1000 : 1 (Typ.) (TM)
Refresh Rate
144Hz
Voltage Supply
5.0V (Typ.)
WEIGHT
2.23/2.43Kgs (Typ./Max.)
Active Area
527.04(W)*296.46(H) mm
Luminance
350 cd/m² (Typ.)
